EMCOD - ML60S24DC Transformer - Magnetic LED Driver - 60W - 24VDC
Default Title
$48.97
Sale price
$48.97
Regular price
$74.20
Skip to product information
Transformer
EMCOD - ML60S24DC Transformer - Magnetic LED Driver - 60W - 24VDC
$48.97
Sale price
$48.97
Regular price
$74.20
Class 2 Magnetic Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure
Black Powder Coated Steel Enclosure
 4008104 |
Conforms to UL STD. 1310 |
| Certified to CSA STD. C22.2 № 223 |
|
| model EM60 | |
|
Link to certification Spec Sheet Installation Instructions |
Transformer
Temperature class B(130°C)
Input leads are 18AWG 600V
Output leads are 18AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 1A
Thermal manually reset secondary breaker 4A
Input leads are 18AWG 600V
Output leads are 18AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 1A
Thermal manually reset secondary breaker 4A
Housing
The actual transformer 60W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 8.13, W = 3.93, D = 1.59
Weight (LBs): 0.39
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 8.13, W = 3.93, D = 1.59
Weight (LBs): 0.39
Electrical Parameters
| Input Voltage: | 120V 60Hz |
| Output voltage without load: | 26.9VDC |
| Output voltage fully loaded: | 23.5VDC |
| Max. Total Wattage: | 60W |
| Max. Output Current: | 2.5A |
| Efficiency: | 85% |
